Waterway 310-1140 1.5 HP Wet End
Waterway | SKU:
310-1140
$9600/ea
Unit price
/
Unavailable
Waterway 310-1140 1.5 HP Wet End is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Description
Description
The Waterway 310-1140 is a wet end assembly for 1.5 horsepower center discharge pump systems. It is constructed from metal, featuring housing components such as a volute and faceplate, and accommodates 1.5-inch x 1.5-inch connections. This assembly is intended for use with 48 frame pumps rated at 115V/15-17 amps or 230V/8 amps, making it suitable for both pool and spa systems requiring these specifications.
Includes: Volute, seal, impeller, wear ring, suction cover, suction cover o-ring, drain plug, drain plug o-ring, suction cover screws
Technical Specifications
| Specification | Details |
|---|---|
| Part Name | Hi-Flo Side Discharge Wet End 1.5 HP |
| Part Number | 310-1140SD |
| Part Type | Wet End |
| Compatibility | Waterway Hi-Flo Series 48 frame pumps |
| Substitute Part Numbers | 5032B, 600018, 806105061669, WWP3101140SD, 3101140SD, WW3101140SDB, WWP310-1140SD |
| Includes | Volute, seal, impeller, wear ring, suction cover, suction cover o-ring, drain plug, drain plug o-ring, suction cover screws |
| Material | Plastic |
| Connection Size | 2 inch intake and discharge |
| Mount Type | Side Discharge |
| Shipping Dimensions | 7.5 x 6 x 5 inch |
| Product Weight | 2.275 pound |
