Intermatic T104P3 24-Hour Mechanical Time Switch

Intermatic  |  SKU: T104P3
$10600 /ea
Inventory: inventory-level-circle 10 In Stock
Shipping: Free 1-3 Day Shipping

Description

The Intermatic T104P3 is a mechanical time switch designed for 208-277 VAC applications, suitable for controlling pumps, heaters, and lighting. Its durable construction with a rainproof enclosure makes it ideal for outdoor use, allowing up to 12 programmable ON/OFF operations per day. This timer is commonly used in pools and spas and comes with a user-friendly dial for easy time setting.

Technical Specs
Specification Details
Part Name Intermatic 24-Hour Mechanical Time Switch
Part Number T104P3
Part Type Timer
Brand Intermatic
Primary Voltage 208-277V
Frequency 60 Hz
Timer Type Mechanical
Timer Configuration 24-Hour
Switch Rating 40A/208-277V
Contact Rating DPST
Enclosure Type NEMA 3R
Enclosure Material Plastic
Mounting Type Wall Mount
Conduit Entries (1) 1/2" and 3/4" combination on back and each side, (2) 1/2" and 3/4" on bottom
Wire Capacity 12 AWG
Temperature Rating -40°F to 130°F
Duty Cycle Continuous
Number of Circuits 1
Load Type Resistive, Inductive, Motor
Maximum Load 40A
Override Function Manual Override
Wire Nuts Included No
Grounding Equipment Ground
Includes Timer mechanism, Enclosure, ON/OFF trippers, Installation manual
Certifications cULus, cCSAus
Warranty 1-Year Limited
Shipping Dimensions 10 x 6.5 x 4 inches
Product Weight 3.75 pounds

Features:

  • 12 ON/OFF operations per day
  • One ON and one OFF tripper included
  • Teeter-type terminals for multiple load connections
  • Highest motor load ratings in the industry
  • Available with pool heater protection
