Intermatic PX300S Pool & Spa Safety Transformer
Intermatic | SKU:
PX300S
$26500/ea
Unit price
/
Unavailable
Intermatic PX300S Pool & Spa Safety Transformer is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Description
Description
Supplies safe low-voltage power to pool/spa lights and other submersible or landscape fixtures - Intermatic PX300S. It isolates line voltage and is suitable for direct connection to underwater luminaires. Features multi-tap 12/13/14 VAC outputs and built-in circuit protection in a stainless steel enclosure.
Includes: Transformer with mounting brackets
Technical Specifications
| Specification | Details |
|---|---|
| Part Name | PX300S |
| Part Number | PX300S |
| Part Type | Pool & Spa Safety Transformer |
| Includes | Transformer with mounting brackets |
| Certifications | UL Swimming Pool Transformer NEC Code 680.23 |
| Material | Stainless Steel |
| Input Voltage | 120 VAC, 60 Hz |
| Output Voltage | 12, 13, 14 VAC |
| Amperage Rating | 3 A |
| Wattage | 300 W |
| Enclosure Type | NEMA 3R |
| Mount Type | Panel |
| Product Dimensions | 7.25 x 5.25 x 4.5 inch |
| Shipping Dimensions | 7.88 x 5.69 x 4.56 inch |
| Product Weight | 10.5 pound |
