Gecko Aqua-Flo XP2e Wet End 3HP
Gecko Aqua-Flo XP2e Wet End 3HP is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Description
Description
The Aquaflo/Gecko 91041930-000 is a wet end unit specifically designed for Gecko AquaFlo XP2 and XP2E pumps. It is composed of key components including the volute, seal, impeller, wear ring, and suction cover, all integrated into a 56-frame housing with a 3.0 horsepower configuration. The unit features 2-inch intake and side discharge connections, and it is compatible with Gecko Flo-Master XP2e and XP2 models, suitable for use in Four Winds Spas and similar systems.
Includes: Volute, seal, impeller, wear ring, suction cover, suction cover o-ring, drain plug, drain plug o-ring, suction cover screws
Technical Specifications
| Specification | Details |
|---|---|
| Part Name | Aqua Flo XP2e 3.0HP Wet End 2" Side Discharge 56 Frame |
| Part Number | 91041930-000 |
| Compatibility | Designed for 56 frame motors compatible with single and dual speed motors |
| Substitute Part Numbers | 27203-300, 27203-300-000, 27203300, 389571, 5038-30, 5121-90, AF91041925000 |
| Part Type | Wet End |
| Includes | Volute, seal, impeller, wear ring, suction cover, suction cover o-ring, drain plug, drain plug o-ring, suction cover screws |
| Material | Commercial-grade materials |
| Valve Type | Side Discharge |
| Number of Positions | 1 |
| Connection Size | 2" male buttress thread |
| Mount Type | 56 frame thru-bolt style motor |
| Flow Paths | Single |
| Pressure Rating | Not specified |
| Seal Material | Viton or Buna |
| Shipping Dimensions | 9.7 x 9.3 x 7.1 inch |
| Product Weight | 3.0 pound |
