Gecko Aqua-Flo XP2e 1.5HP Wet End 56 Frame
Aquaflo/Gecko | SKU:
91041915-000
$12400/ea
Unit price
/
Unavailable
Gecko Aqua-Flo XP2e 1.5HP Wet End 56 Frame is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Description
Description
The Aquaflo/Gecko 91041915-000 is a wet end component for the 1.5 HP, 56 Frame Aqua-Flo Flo-Master XP2e series pumps. It features a 2-inch side discharge with male buttress thread connections and measures 6.3 inches. This part is specifically compatible with the AquaFlo XP2 and XP2E pump series.
Includes: Complete wet end assembly including volute, seal assembly, impeller, wear ring, volute o-ring, suction cover, drain plug with o-ring, and screws
Technical Specifications
| Specification | Details |
|---|---|
| Part Name | Gecko Aqua-Flo FMXP2e Wet End |
| Part Number | 91041915-000 |
| Part Type | Wet End |
| Compatibility | Aqua-Flo XP2/XP2E 56-Frame Pumps |
| Substitute Part Numbers | 1-05-0100 |
| Includes | Complete wet end assembly including volute, seal assembly, impeller, wear ring, volute o-ring, suction cover, drain plug with o-ring, and screws |
| Material | Plastic |
| Horsepower | 1.5 HP |
| Frame Size | 56Y |
| Discharge Size | 2-inch MBT |
| Discharge Location | Side |
| Series | FMXP2e |
| Configuration | Standard Duty (SD) |
| Impeller Part Number | 91695150 |
| Impeller Dot Color | Yellow & Silver |
| Impeller Operational HP | 1.5 HP |
| Impeller Total HP | 2.0 HP |
| Impeller Vane Count | 6 |
| Impeller Diameter | 4.45 inches |
| Impeller Total Length | 3.27 inches |
| Impeller Vane Gap | 0.51 inches |
| Impeller Shaft Outer Diameter | 0.63 inches |
| Impeller Intake Inner Diameter | 2.4 inches |
| Impeller Intake Outer Diameter | 2.6 inches |
| Shaft Seal Type | PS-200 |
| Shaft Seal Material | Viton |
| Shaft Seal Shaft Size | 0.625 inches |
| Volute Part Number | 92770725 |
| Volute Diameter | 6.3 inches |
| Volute Frame Size | 56 Frame |
| Volute Mounting Bolt Center-to-Center Distance | 4.125 inches |
| Shipping Dimensions | 15 x 10 x 10 inch |
| Product Weight | 3.19 pounds |
