2.0 HP 230V 2-Speed 56Y Motor

Century | SKU: B2233

$451⁹⁹^/ea

5-digit zip required

2.0 HP 230V 2-Speed 56Y Motor

The Century B2233 is a 2.0 HP, 230V, two-speed AC motor built on a 56Y frame with a threaded shaft and thru-bolt mounting for spa and pool pump wet-ends.

Key Features

Two-speed operation, 3450/1725 RPM
Thru-bolt construction, threaded shaft
Capacitor mounted on top
Rigid base mount
7.4A / 1.4A motor amperage

Compatibility

Balboa Water Group Dura-Jet DJ Series pumps
Jacuzzi Piranha "A" pump
Waterway Mustang/Workhorse pump
Waterway Executive 56-frame wet-ends
Waterway EX2 spa pump, 48/56-frame
Waterway Viper 56-frame 2-1/2" spa pump
Gecko Aqua Flo Flo-Master XP2 56-frame (6.3" diameter)
Gecko Aqua Flo Flo-Master XP2E 56-frame

Capacitor On Top

Yes

Frame Type

56Y

Horsepower

2.0hp

Manufacturer

Century

Motor Amperage

7.4A/1.4A

Motor Shaft Type

Threaded

Motor Style

Thru Bolt

Motor Type

Spa

Phase

1 Phase (1ph)

Speed

2 Speed (2-Spd)

Total Horsepower

2.0thp

Voltage

230v
